Description
The SycamoreLED 4 Zone Remote Control (SY9565A) is the ideal companion to the Pulse Smart Receiver (SY5002). It uses 2.4GHz RF wireless transmission to give you convenient manual control of up to 4 independent lighting zones — dimming brightness from 0–100% and adjusting colour temperature on CCT tunable LED lighting. Because it operates on Radio Frequency rather than infrared, the receivers can be hidden completely out of sight — behind plinths, on top of cabinets, or inside niches — with no line-of-sight required.
Key Features
-
4 independent lighting zones — control up to 4 separate areas from one remote
-
Full dimming control — adjust brightness from 0 to 100%
-
CCT colour temperature adjustment — compatible with single colour and CCT tunable LED lighting
-
2.4GHz RF wireless — no line of sight required; receivers can be hidden behind plinths or cabinets
- 30m control distance
-
On/off switching via remote
- Compatible with 12Vdc and 24Vdc LED systems
- 2 x AAA batteries included
Technical Specification
-
SKU: SY9565A
-
Transmission Technology: 2.4GHz RF Wireless
-
Number of Zones: 4
-
Compatible Lighting: Single Colour LED, CCT Tunable LED
-
Rated Voltage: 12Vdc / 24Vdc
-
Control Distance: Up to 30m
-
Dimming Range: 0–100%
-
Power: 2 x AAA batteries (included)
Complete Your Installation
Frequently Asked Questions
What lighting can I control with the SY9565A?
It is compatible with both single colour LED lighting (dimming only) and CCT tunable LED lighting (dimming and colour temperature adjustment), operating at 12Vdc or 24Vdc.
Does it need line of sight to work?
No — the SY9565A uses 2.4GHz Radio Frequency transmission, so receivers do not need to be visible. They can be hidden behind plinths, on top of cabinets, or inside ceiling voids, with a control distance of up to 30 metres.
How many zones can I control?
This remote controls up to 4 independent lighting zones, allowing you to adjust different areas of a room or multiple rooms separately.
What receiver does this pair with?
It is designed for use with the Pulse Smart Receiver (SY5002). Each receiver supports up to 12 remotes, with a range of up to 30 metres.
Are batteries included?
Yes — 2 x AAA batteries are included in the box.
